B&R X20 Digital Input Module (HF Series)
The B&R X20 Digitales Eingangsmodul, part of the High Feature (HF) Serie, bietet 32 independent 24V DC digital input channels. Each channel is electrically isolated, enhancing noise immunity and ensuring system safety. This robust design helps maintain reliable operation even in challenging industrial environments.
Zusätzlich, the module supports advanced diagnostic functions, including wire-break detection and overvoltage protection, allowing for proactive system monitoring and increased uptime. Users can configure and monitor the module conveniently through B&R’s Automation Studio software, making integration into existing systems seamless.
Its plug-and-play design simplifies installation and maintenance, reducing setup time and minimizing potential errors. This makes the module an ideal I/O component for building efficient, sicher, and reliable automation systems. With its combination of flexibility, Diagnostik, und Benutzerfreundlichkeit, the B&R X20 Digital Input Module is a dependable choice for modern industrial applications.
Produktparameter
| Parameter | Einzelheiten |
| Modell | 8LSA44.E3030D100-0 |
| Serie | B&R X20 System |
| Modultyp | 32-channel Digital Input Module (High Feature HF Series) |
| Anzahl der Eingänge | 32 Punkte |
| Eingabetyp | Senke/Quelle (PNP/NPN) |
| Rated Input Voltage | 24In DC (Standard industrial voltage) |
| Eingangsstrom | Typischerweise 3-4 mA pro Kanal (at 24V DC) |
| Isolierung | Group isolation between channels |
| Connection | Via high-density connector (z.B., D-Sub 37-pin) |
| Diagnostic Functions | Unterstützt, z.B., power supply monitoring, short-circuit detection (depending on specific model configuration) |
| Montage | Standard X20 system bus module, left-side bus connection, right-side I/O connection |
