The A06B-0116-B855 is a Spindle Servo Amplifier from FANUC’s αi Series (specifically the αiF series). This model is a key power module within FANUC CNC Systems (such as Series 0i, 30I, 31I, 32I, itp.) used to drive AC spindle motors. This amplifier integrates PWM control, current detection, and protection circuits. It receives spindle control commands from the CNC and outputs precise three-phase AC power to drive the spindle motor, enabling high-precision speed control, positioning control, and functions like rigid tapping.
Szczegółowy opis:
-
High-Performance Spindle Drive: Based on FANUC’s advanced digital servo technology, it provides high dynamic response and a wide speed range, meeting the demands of various machine tool spindles from low-speed heavy cutting to high-speed finishing. Supports high-resolution position feedback, enabling high-precision functions such as Spindle Orientation I Cs Axis Contouring Control.
-
Compact Integrated Design: This amplifier module is typically designed as a compact unit that can be integrated into the amplifier frame of the CNC system. It may include a Power Supply Module (PSM), A Spindle Amplifier Module (SPM), and necessary interfaces, with the exact configuration depending on the full model and system integration.
-
Powerful Communication and Integration: Connected to the CNC controller via a high-speed serial bus (such as FSSB or I/O Link i), enabling real-time command transmission and status monitoring. Contains a rich set of parameters for fine performance tuning and function configuration via the CNC system or dedicated servo adjustment software.
-
Comprehensive Protection and Diagnostics: Equipped with complete protection functions including overcurrent, overvoltage, undervoltage, przegrzanie, przeciążać, and ground fault protection. Provides detailed alarm codes and status information displayed on the CNC screen or via LED indicators, facilitating quick fault identification and maintenance.
-
High-Reliability Design: Utilizes industrial-grade components and optimized thermal design (typically with a forced cooling fan) to ensure long-term stable operation in harsh machine tool environments. Modular design facilitates installation and maintenance within the system.
Kluczowe dane techniczne:
| Parametr | Bliższe dane / Typical Features |
| Model | A06B-0116-B855 |
| Szereg | FANUC αi Series (αiF) |
| Typ modułu | Spindle Servo Amplifier (SPM) |
| Compatible CNC Series | Series 0i-F, 30i/31i/32i-B, itp. |
| Driven Motor Type | FANUC αiI/αiF series AC spindle motors |
| Maximum Output Power | Refer to specific catalog, matched to motor (np., for 16kW or a specific current class) |
| Input Power | Three-phase 200V AC (common) or 400V AC (depends on specification) |
| Metoda kontroli | Sine wave PWM control, Sterowanie wektorem |
| Interfejs opinii | Supports high-resolution serial position detectors (np., motor-built-in encoder) |
| Interfejs komunikacyjny | Connects to CNC via FSSB or I/O Link i |
| Main Control Functions | Speed Control, Spindle Orientation, Rigid Tapping, Cs Contour Control |
| Protection Functions | Overcurrent, Overvoltage, Undervoltage, Przegrzanie, Przeciążać, Ground Fault, itp. |
| Metoda chłodzenia | Forced Air Cooling (built-in fan) |
| Temperatura pracy | 0 ~ 55°C (or per specification) |
| Mounting Method | Modułowy, mounted within the amplifier unit frame |
