Detailed Description:
-
Compact and Efficient Power Module: Features a booksize modular design, compact in structure, allowing for high-density arrangement on mounting plates and effectively saving control cabinet space. As a non-regenerative module, it relies on an external Power Module (e.g., Basic or Active Line Module) to provide a stable DC link voltage.
-
High-Performance Servo and Vector Control: The module itself does not contain control logic; this is implemented by the upper-level Control Unit (CU). It precisely executes commands from the Control Unit, enabling High-Performance Servo Control (for synchronous motors) and Vector Control (for induction motors) of the connected motor, delivering exceptional dynamic response and speed control accuracy.
-
Integrated DRIVE-CLiQ Communication: The core interface of the module is DRIVE-CLiQ, a high-speed real-time communication system for the SINAMICS family. Via DRIVE-CLiQ, the module exchanges data with the Control Unit, encoders, and other system components, enabling automatic parameter configuration, motor identification, and comprehensive status diagnostics, greatly simplifying commissioning and maintenance.
-
Intelligent Cooling and Comprehensive Protection: Equipped with an efficient internal cooling fan to ensure stable operation under rated load. The module incorporates comprehensive electronic protection functions including overcurrent, overvoltage, undervoltage, overheating, and short-circuit protection. Clear fault information is provided via LED status indicators and the TIA Portal engineering software.
-
Support for Integrated Safety Functions: The module design supports Integrated Safety Functions (such as Safe Torque Off – STO, Safe Stop 1 – SS1), complying with relevant safety standards (e.g., IEC 61800-5-2, SIL 3, PL e). This allows for safe shutdown directly at the drive level without additional external safety relays, enhancing system safety and integration.
-
Broad Applicability: Suitable for driving various series of Siemens servo motors (e.g., 1FK7, 1FT7) and standard induction motors. Widely used in machine tools, packaging, printing, material handling, and various high-performance multi-axis synchronous motion control applications.
Key Specifications:
| Parameter | Details |
| Model | 6SL3120-2TE13-0AA0 |
| Series | SINAMICS S120 |
| Module Type | Booksize Single Motor Module (Non-Regenerative) |
| Rated Output Current | 13 A |
| Maximum Output Current (Overload) | 18 A (for 60 s), 26 A (for 3 s) |
| Power Connection | DC Link Input (connected to system DC link) |
| Output Voltage Range | 0 – DC link voltage supplied by the Power Module |
| Output Frequency Range | 0 – 650 Hz |
| Control Methods | Servo Control / Vector Control (implemented by Control Unit) |
| Communication Interface | DRIVE-CLiQ |
| Cooling Method | Internal Fan Cooling (Forced-air) |
| Safety Functions | Supports Integrated Safety Functions via DRIVE-CLiQ (e.g., STO) |
| Protection Class | IP20 |
| Operating Temperature | 0 – 55 °C |
| Mounting Style | Booksize, mounted side-by-side |
