Product Details
- Display Characteristics: 5.7-inch monochrome STN LCD display, QVGA resolution (320×240), 4 gray scales
- Operation Interface: Equipped with 8 system keys, 8 function keys (with LED indicators) and 4 cursor keys for intuitive operation
- Communication Capability: Integrated PROFIBUS DP interface supporting transmission rates up to 12Mbps, easily integrated into automation systems
- Protection Performance: Front panel protection rating IP65, dustproof and waterproof, oil resistant, suitable for harsh industrial environments
- Mounting Method: Supports panel mounting, cutout dimensions 138x108mm, mounting depth 47mm
- Programming Software: Uses Siemens WinCC flexible engineering configuration software for project design and commissioning
Product Parameters
| Parameter | Value |
| Display Size | 5.7-inch |
| Resolution | 320×240 pixels (QVGA) |
| Display Type | Monochrome STN LCD |
| Display Colors | Monochrome (4 gray scales) |
| Backlight Life | Approx. 50,000 hours |
| Control Elements | 8 system keys, 8 function keys, 4 cursor keys |
| Communication Interface | PROFIBUS DP |
| Transmission Rate | 9.6Kbps to 12Mbps |
| Protection Rating | IP65/NEMA 4 (Front Panel) |
| Operating Temperature | 0~50°C |
| Storage Temperature | -20~60°C |
| Power Supply Voltage | 24V DC |
